Triple-Camera USB Endoscope for Multi-Direction Cavity Inspection

Name: Triple-Camera USB Endoscope for Multi-Direction Cavity Inspection
SKU: 15831
Price: 1.00 USD
Availability: InStock

$1.00

1MP triple-camera USB endoscope module with 1 forward + 2 side cameras, Fixed Focus, D76° FOV, 7.9mm IP67 stainless-steel camera head, 8 forward LEDs + 1 LED per side camera and USB 2.0 interface.

—————————————————————————————–
Price is for reference only. Please contact us for the latest quotation.

... people are viewing this right now

Description Send Inquiry

Introduction

In a narrow cavity, adding more viewing directions only helps if each camera can actually see the surface it is aimed at.

This three-camera design combines one forward-view camera and two side-view cameras inside a 7.9mm inspection head. More importantly, the lighting follows the viewing structure: the forward camera uses eight white LEDs, while each side camera has its own dedicated white LED.

This makes the module particularly relevant to inspection devices where the operator needs to observe the path ahead and both side walls without relying entirely on probe rotation or front-facing illumination.

Applications in Real Devices

Pipe Wall Inspection

Cracks, deposits or surface changes may appear on either side of a pipe rather than directly ahead. Two side cameras give the device dedicated lateral views while the forward camera continues to guide insertion.

Internal Equipment Cavity Inspection

Inside housings or machinery, the target may appear on different surfaces around the probe. Three viewing directions allow the inspection head to check more surrounding areas from one insertion position.

Multi-Surface Borescope Systems

Some inspection tasks require the operator to compare forward and side surfaces rather than examine only one direction. A three-camera structure supports this workflow without requiring a separate camera head for each viewing angle.

Dark Enclosed Inspection Areas

When little ambient light reaches the inspection area, the side cameras cannot depend only on illumination projected forward. Dedicated side LEDs provide lighting closer to the actual side-view direction.

Project Evaluation Guide

Consider This Model When

The inspection requires one forward and two side views.
Both side walls may contain the target.
Side cameras need their own local illumination.
A 7.9mm camera head fits the access opening.
Fixed Focus around 5cm matches the inspection task.
USB 2.0 is suitable for the host system.
IP67 protection is required for the camera head.

Confirm Before Sampling

Minimum access diameter.
Which surfaces must be inspected.
Real camera-to-target distance.
Surface reflectivity and LED requirement.
Whether the system displays one view or multiple views.
Cable length and routing.
USB host and software architecture.
Exposure conditions beyond normal IP67 use.

Choosing This Model Within the Endoscope Camera Series

Choose this model when the project requires three viewing directions and dedicated illumination for each direction.

Its key difference from SF-SPU65-3A29 is not simply that both are three-camera designs. This model uses 8 LEDs around the forward camera plus one LED for each side camera, making the lighting arrangement a more important part of its positioning.

Related Models

SF-SPU65-3A29
Choose this three-camera alternative when the project needs forward and dual-side viewing with a different illumination configuration.

SF-SPU65-2A29
Choose this dual-camera model when only one side view is required.

Key Specifications

Specification	Details
Product Name	Triple-Camera USB Endoscope
Model	SF-SPA65-3A34
Sensor Type	CMOS
Resolution	1MP / 1280 × 720
Frame Rate	720P @ 18fps
Sensor Size	1/9 inch
Pixel Size	1.4μm × 1.4μm
Focus Type	Fixed Focus
Field of View	D76°
Aperture	F2.8
Focus Distance	5cm
Camera Layout	1 Forward + 2 Side
Camera Head Diameter	7.9mm
Module Size	27 × Ø7.9mm
Housing	Integrated Stainless-Steel Sleeve
Protection	IP67
Forward LEDs	8 × White SMD LEDs
Side LEDs	1 × White SMD LED per Side Camera
AEC / AGC / White Balance	Auto
ADC Accuracy	10-bit
Interface	USB 2.0
Power	5V
Operating Temperature	0°C to +50°C

SincereFirst Customization

Multi-Direction Camera Layout

The forward and two side-camera directions can be evaluated according to the surfaces that need to be inspected.

Directional LED Configuration

Forward and side illumination can be adjusted according to target distance, cavity shape and surface reflectivity.

Focus Configuration

The focus setting of each viewing direction can be evaluated according to the actual inspection distance.

Device Integration

Cable routing, USB connection, camera switching and mechanical structure can be adapted to the final endoscope design.

Final configuration should be validated with the actual host platform, enclosure, optics, software, and lighting environment before sampling.

FAQ

Do all three cameras use the same illumination?

No. The forward camera uses eight white LEDs, while each side camera has one dedicated white LED.

When is a three-camera head worth choosing over a dual-camera design?

When important targets may appear on both side walls as well as directly ahead. If only one side direction matters, a dual-camera structure may be sufficient.

Can the side cameras completely eliminate probe rotation?

Not necessarily. They reduce dependence on rotation, but the final inspection coverage still depends on cavity geometry, camera orientation and target position.

Why should side-lighting be evaluated separately?

A side-facing camera observes a surface at a different angle from the front camera. Light projected forward may not illuminate that surface effectively.

Does IP67 mean it can be used in any liquid environment?

No. Pressure, chemicals, prolonged immersion and temperature should be evaluated separately.

Evaluate This Module for Your Device
