1MP dual-camera USB endoscope module with 1 forward + 1 side camera, Fixed Focus, D78° FOV, 7.9mm IP67 stainless-steel camera head, 8+1 white LEDs, USB 2.0 and Android/iOS support.

—————————————————————————————–
Price is for reference only. Please contact us for the latest quotation.

... people are viewing this right now

Description Send Inquiry

Introduction

For field inspection, the imaging head is only one part of the device. The host platform also determines how portable the final product can be.

This dual-camera design combines one forward-view camera and one side-view camera with USB 2.0 and Android/iOS system support, making it particularly relevant to inspection products built around smartphones, tablets or other mobile terminals.

The forward camera is focused around 5cm and uses eight white LEDs, while the side camera is focused around 4cm with its own LED. This creates a compact forward-and-side inspection structure for mobile workflows.

Applications in Real Devices

Smartphone Inspection Accessories

A mobile host can provide the display, interface and application environment while the camera head performs the actual inspection. This is useful for portable inspection products where a dedicated monitor would add unnecessary size.

Field Maintenance Tools

Technicians working away from a fixed workstation may need a camera that connects to a portable host. Forward and side views allow different surfaces to be checked without carrying a larger inspection system.

Portable Automotive Inspection

A phone- or tablet-based device can be used to view internal areas while the dual-camera head handles both insertion direction and nearby side surfaces.

Mobile Pipe and Cavity Inspection

Where only one side direction is required, a dual-camera head provides more coverage than a single-view probe without moving to a three-camera structure.

Project Evaluation Guide

Consider This Model When

The final device uses an Android or iOS host.
One forward and one side view are required.
Portable inspection is a priority.
A 7.9mm head fits the access space.
5cm forward and 4cm side focus suit the task.
USB 2.0 fits the connection architecture.
Integrated white illumination is required.

Confirm Before Sampling

Exact Android/iOS host device.
USB host capability.
Connector and adapter design.
Application software requirements.
Required image-switching method.
Access diameter.
Forward and side working distances.
Cable length.

Choosing This Model Within the Endoscope Camera Series

This model represents the mobile dual-camera direction.

Choose it when the project needs forward-and-side inspection while the final product is designed around an Android or iOS terminal.

Compared with SF-SPU65-2A29, the key selection point is the mobile host ecosystem, not simply the number of cameras.

Related Models

SF-SPU65-2A29
Choose this model for a conventional USB dual-camera inspection system without the same Android/iOS positioning.

SF-SPU55-29A
Choose this smaller 6.35mm single-camera model when access diameter matters more than side viewing.

Key Specifications

Specification	Details
Product Name	Mobile Dual-Camera Endoscope
Model	SF-SPIOS55-2A09
Sensor Type	CMOS
Resolution	1MP / 1280 × 720
Frame Rate	720P @ 18fps
Sensor Size	1/9 inch
Pixel Size	1.4μm × 1.4μm
Focus Type	Fixed Focus
Field of View	D78°
Aperture	F2.8
Forward Focus Distance	5cm
Side Focus Distance	4cm
Camera Layout	1 Forward + 1 Side
Camera Head Diameter	7.9mm
Module Size	18.5 × Ø7.9mm
Housing	Integrated Stainless-Steel Sleeve
Protection	IP67
Forward LEDs	8 × White SMD LEDs
Side LED	1 × White SMD LED
AEC / AGC / White Balance	Auto
Interface	USB 2.0
Power	3.3V / 5V
System Support	Android / iOS
Operating Temperature	0°C to +60°C

SincereFirst Customization

Forward and Side Focus

The forward and side focus distances can be evaluated according to the actual inspection geometry and target position.

Lens and Viewing Direction

Lens configuration and side-camera orientation can be adjusted according to the required viewing area.

Android and iOS Integration

Cable type, connector direction and USB connection can be evaluated according to the target phone, tablet or mobile terminal.

LED Configuration

Forward and side illumination can be reviewed according to working distance and the lighting conditions inside the inspection area.

Final configuration should be validated with the actual host platform, enclosure, optics, software, and lighting environment before sampling.

FAQ

Does Android and iOS support mean the camera works with every phone?

No. The operating system is only one part of compatibility. USB host support, connector type, permissions and application software must also match.

What should be confirmed before developing the mobile app?

Confirm how the host detects the camera, how the two views are switched or displayed and what USB connection architecture is used.

Why do the forward and side cameras use different focus distances?

The side wall normally sits closer to the camera body than the area directly ahead, so the two directions benefit from different focus settings.

When is this preferable to a PC-based dual-camera model?

When portability and mobile-terminal integration are part of the final product requirement.

Is a three-camera version necessary for mobile inspection?

Only if both side directions need to be observed. If one side view is sufficient, a dual-camera structure may be simpler.
