The Sony IMX577 is a 12.3 megapixel high-resolution (12MP) stacked CMOS USB image sensor camera module using Sony technology, which is known for its excellent image quality and performance. It can capture images at high speed using column-parallel A/D conversion circuits. The back-illuminated (BSI) pixel structure enables high sensitivity and low noise. The diagonal size is 7.857 mm (1/2.3 type), the output interface is UVC-compliant USB 3.0, plug-and-play, supports Linux, Android, Mac, Windows, Raspberry Pi, etc., the frame rate is up to 18 fps at full resolution, and has special features such as high dynamic range (HDR), Exmor RS sensor technology (for low-light performance) and rolling shutter mode. There are autofocus or fixed focus options. This module is widely used in outdoor photography, baby monitoring systems, advanced smart toys, medical equipment, industrial inspection, machine vision, Internet of Things, etc.
