OV48B2Q 48MP RAW10 MIPI Autofocus Camera Module for High-Detail Embedded Imaging

Name: OV48B2Q 48MP RAW10 MIPI Autofocus Camera Module for High-Detail Embedded Imaging
SKU: 15293
Price: 1.00 USD
Availability: InStock

$1.00

OV48B2Q 48MP MIPI autofocus camera module with 8000×6000 resolution, 4K30fps, RAW10 output, PDAF, HDR, D80.1° FOV and 20Pin BTB integration for embedded imaging devices.

—————————————————————————————–
Price is for reference only. Please contact us for the latest quotation.

... people are viewing this right now

Description Send Inquiry

Introduction

SF-SC48B2Q-C6102-B V3.0 is a 48MP MIPI Camera Module designed for embedded devices that require high-resolution RAW imaging, Autofocus and a compact 20Pin BTB connection.

Based on the OV48B2Q CMOS sensor, it supports up to 8000×6000 resolution and 4K at 30fps, together with 4-in-1 pixel technology, PDAF and HDR. The module combines VCM Autofocus with a D80.1° optical configuration and TV distortion below 1.5%, making it particularly relevant to systems that need high image detail without moving toward an ultra-wide optical design.

Its main selection value within the 8K Series is the combination of 48MP RAW10 imaging, standard-angle low-distortion optics and compact 20Pin MIPI integration.

Applications in Real Devices

Embedded AI Recognition Equipment

For AI devices that need access to detailed sensor data before host-side processing, 48MP RAW10 output provides a high-resolution source for recognition, classification and image-analysis pipelines.

The final benefit depends on whether the host ISP and algorithm can make effective use of the additional image detail.

High-Resolution Inspection Devices

For inspection systems observing components, printed information or fine surface features, the 8000×6000 sensor resolution provides additional spatial information for cropping and detailed analysis.

The D80.1° lens direction provides broader scene coverage without moving into the strong distortion characteristics of an ultra-wide lens.

Project Evaluation Guide

Consider This Model When

48MP / 8000×6000 native image detail is required.
RAW10 output is needed for host ISP processing.
VCM Autofocus is required for variable target distances.
PDAF and HDR are useful to the imaging architecture.
A D80.1° standard-angle optical direction matches the scene.
Low TV distortion is important to the visual task.
A 20Pin BTB MIPI connection fits the host-board design.

Confirm Before Sampling

Host processor support for the OV48B2Q sensor and RAW10 data.
MIPI lane and electrical requirements.
ISP tuning requirements for HDR, color and Autofocus.
Working-distance range and Autofocus behavior.
Required FOV and acceptable distortion.
20Pin connector pinout and host-board compatibility.
FPC direction, module height and enclosure clearance.
Whether full 48MP capture or 4K30 is the primary operating requirement.

Choosing This Model Within the 8K Camera Module Series

SF-SC48B2Q-C6102-B V3.0 is the 20Pin OV48B2Q Autofocus MIPI direction within the 8K Camera Module Series. Choose it when the project requires 48MP RAW imaging, Autofocus and a relatively standard D80.1° optical configuration, while the host hardware is designed around a compact 20Pin BTB connection.Its key difference from the other OV48B2Q models is not sensor capability alone. Connector structure and optical architecture are the real selection factors: the SP153E-B version provides a 30Pin BTB direction, while SF-SC48B20-3030524548-B uses a much wider D120° optical design with a long FPC structure.

Related Models

OV48B2Q 30Pin MIPI – SF-SC48B2Q-SP153E-B V1.0
Consider this model when the same 48MP OV48B2Q platform is required but the host architecture uses a 30Pin BTB connection.

OV48B2Q D120° Long-FPC – SF-SC48B20-3030524548-B V1.0
Consider this model when the project prioritizes ultra-wide scene coverage and a long-FPC structure rather than the standard D80.1° optical direction.

Key Specifications

Specification	Details
Model	SF-SC48B2Q-C6102-B V3.0
Sensor	OV48B2Q CMOS
Resolution	48MP / 8000 × 6000
Sensor Size	1/2 inch
Pixel Size	0.8μm × 0.8μm
4K Video	3840 × 2160 @ 30fps
Pixel Technology	4-in-1 Pixel
PDAF	Supported
HDR	Supported
Output Format	10bit RAW
Focus	VCM Autofocus
Field of View	D80.1°
TV Distortion	<1.5%
Interface	MIPI
Connector	20Pin BTB
Module Process	COB

SincereFirst Customization

Lens and Optical Configuration

The standard optical direction provides approximately D80.1° coverage with TV distortion below 1.5%. FOV, focal length and optical structure can be evaluated when the target size, working distance or enclosure requires a different viewing direction.

Autofocus Configuration

VCM Autofocus is the standard focus architecture. Focusing behavior can be evaluated according to target-distance range, scene contrast and host-side control requirements.

MIPI and 20Pin BTB Integration

The standard design uses a 20Pin BTB MIPI interface. Connector compatibility, pin definition, MIPI configuration and FPC routing should be evaluated together with the target processor and host PCB.

RAW10 and ISP Tuning

RAW10 output allows the host to control the image-processing pipeline. ISP tuning requirements for color, HDR, Autofocus and

application-specific image quality can be evaluated according to the final platform.

Final configuration should be validated with the actual host platform, enclosure, optics, software, and lighting environment before sampling.

FAQ

What is the main reason to choose this 20Pin OV48B2Q version?

Choose it when the host-board architecture specifically benefits from a compact 20Pin BTB connection while the project still requires 48MP RAW10 imaging, Autofocus and standard-angle low-distortion optics.

How should I choose between the 20Pin and 30Pin OV48B2Q modules?

Do not select between them from image resolution because both belong to the same 48MP sensor direction. The more important questions are connector pinout, host-board compatibility, FPC layout and mechanical space.

When is D80.1° preferable to the D120° OV48B2Q version?

D80.1° is more suitable when the device needs a more controlled field of view and lower optical distortion. D120° is more useful when broad scene coverage is more important, but the target will occupy fewer pixels within the frame and stronger distortion must be accepted or corrected.

Does RAW10 mean the module can produce a finished image without ISP development?

No. RAW10 is sensor-level image data. The host platform needs an appropriate sensor driver and ISP pipeline to convert it into the final image quality required by the device.

Why are PDAF and VCM both relevant to Autofocus?

The VCM physically moves the lens, while PDAF provides focusing information that can be used by the Autofocus system. Actual focusing behavior still depends on the sensor driver, lens, actuator control and ISP/software implementation.

Is 48MP always preferable to using the 4K30 mode?

No. Native 48MP capture is useful when maximum detail is required, while 4K30 is more appropriate for continuous video. The host bandwidth, processing capability and actual visual task determine which mode provides more project value.

Evaluate This Module for Your Device

Share your host processor, MIPI/20Pin interface conditions, RAW/ISP requirements, working-distance range, required FOV and available FPC/module space. SincereFirst can evaluate whether this D80.1° Autofocus configuration matches the device before sampling.
