This is the SincereFirst high-definition 12.5mm diameter 12MP integrated LED endoscope camera module. It is equipped with a CMOS color image sensor, featuring 12MP high-definition pixels and supporting 3840×3104 resolution output. The maximum frame rate can reach 30FPS, ensuring clear and smooth dynamic images. The sensor size is 1/3.06 inch, and the pixel size is 1.12μmx1.12μm. Cooperating with the F2.2 large aperture, it effectively enhances the light – capturing ability. The lens has a field of view of 80.9°, and the depth of field covers from 3.5cm to infinity. Combined with the autofocus function, it can quickly lock onto observation targets at different distances. The module adopts a USB2.0 interface and supports the UVC protocol, enabling plug – and – play for convenient adaptation to various devices. The integrated design makes the structure more compact, with a lens diameter of only 12.5mm, and it also integrates 8 LED lamp beads to provide sufficient supplementary light. As a bare module product, its production process adopts high – precision SMT technology and AA process to ensure the stability and consistency of the module.
In fields such as medical diagnosis, industrial testing, and precision maintenance, the performance of endoscope camera modules directly determines the observation accuracy and operational efficiency. Among them, the lens diameter, as a core parameter affecting device adaptability, has become a key consideration during selection. As a brand dedicated to providing high-quality camera module solutions, SincereFirst has launched an endoscope camera module with a 12.5mm lens diameter. Relying on precise parameter design and technological innovation, it demonstrates unique advantages in narrow space observation scenarios while also facing technical challenges brought by the small size.
For more information or customization options, contact SINCEREFIRST, your trusted partner in integrated optical devices and optical imaging solutions.
