Product Introduction:
This 4K Resolution 13MP Sony IMX258 CMOS HDR Autofocus MIPI Camera Module is an imaging solution integrating high-performance hardware and mature craftsmanship. It is powered by the Sony IMX258 CMOS color image sensor as its core, featuring a 13MP high-resolution specification and capable of stably outputting 4K@30FPS high-definition images, laying a solid foundation for image quality presentation.
In terms of core hardware parameters, the sensor size reaches 1/3.06 inch with a pixel size of 1.12μm x 1.12μm. It also integrates Exmor RS stacked BSI technology and PDAF phase-detection autofocus technology. With the support of these two technologies, it balances light-sensing performance and focusing efficiency. Additionally, the module supports HDR (High Dynamic Range) function, with a measured dynamic range of 72dB, enabling it to handle complex light ratio environments with ease.
In terms of optical configuration, the module has a depth of field ranging from 10cm to infinity, an Effective Focal Length (EFL) of 3.34mm, and an aperture specification of F2.2±5%. It offers a wide field of view, including a Diagonal Field of View (DFOV) of 80.3°, Horizontal Field of View (HFOV) of 68.5°, and Vertical Field of View (VFOV) of 53.6°, with distortion controlled within 1.5%. Equipped with a 5P lens structure and autofocus design, it further ensures the clarity and regularity of imaging. For the interface, it adopts the mainstream MIPI interface, which is compatible with the transmission needs of most terminal devices.
The production process is completed in SincereFirst’s Class 10/100 COB cleanroom, integrating SMT (ROHS-compliant), COB processes, and AA (Active Alignment) process. Strict control is implemented throughout the entire process from production environment to core craftsmanship, ensuring excellent product consistency and reliability.
Product Advantages & Features
- High Resolution and Outstanding Dynamic Range: The 13MP high pixel count combined with a 72dB wide dynamic range retains rich image details even in high-contrast scenarios such as strong light and backlight, effectively avoiding overexposure and underexposure to restore the true texture of the image.
- Advanced Light-Sensing and Fast Focusing Technology: The Exmor RS stacked BSI structure enhances light-sensing efficiency, and when combined with PDAF phase-detection autofocus, it achieves millisecond-level accurate focusing. Whether for dynamic capture or static shooting, it can quickly lock the focus to meet the shooting needs of diverse scenarios.
- Compact Design and High-Quality Optical Performance: The 5P lens structure effectively controls distortion (<1.5%) to prevent edge stretching and deformation of the image. Matched with an F2.2 large aperture, it provides good light transmittance, resulting in better low-light imaging performance. Meanwhile, its compact size is suitable for various space-constrained application scenarios, allowing integration without excessive adjustments to the device structure.
- Industrial-Grade Reliability and Consistency: Backed by SincereFirst’s over 30 years of experience in the optical device and camera module industry, as well as mature technical and operational capabilities, the module adopts SMT + COB (produced in Class 10/100 cleanrooms) + advanced AA process. This ensures the module works stably in complex environments such as high temperatures and dust, providing a long and reliable service life.
Product Application
- Smartphones: It meets the needs of daily shooting and 4K video recording. The HDR function optimizes the shooting effect of backlit portraits and landscapes, while PDAF improves the success rate of dynamic capture. Its compact design and MIPI interface are compatible with the lightweight trend of smartphones, providing a cost-effective imaging solution for mid-range models.
- Smart Access Control and Security: The 72dB wide dynamic range effectively handles scenarios with strong light backgrounds such as doorways and windows, ensuring clear face recognition. The 5P lens guarantees the image edge quality and avoids recognition accuracy issues caused by distortion, making it suitable for access control and monitoring needs in homes and offices.
- Automotive Imaging Systems: Its wide operating temperature range adapts to complex automotive environments. The HDR function balances sudden light changes such as those inside and outside tunnels, as well as between day and night, improving image clarity and contributing to driving safety. At the same time, it supports customized adjustments according to the needs of automotive equipment, better matching different functions such as surround view and driving recording.
- Industrial Machine Vision Inspection: The 13MP high resolution supports the surface defect inspection of small electronic components and precision parts. The autofocus function adapts to workpieces of different heights, and the wide dynamic range solves the imaging problem of reflective surfaces such as metal and glass. Additionally, relying on SincereFirst’s one-stop OEM/customization solutions, parameters can be flexibly adjusted according to the characteristics of the inspected objects to adapt to diverse production scenarios.
- IoT Smart Devices: Its low-power design and compact shape make it very suitable for IoT applications such as smart homes and smart retail, supporting AI functions like face recognition and behavior analysis. Moreover, with the support of one-stop customization services, the module design can be optimized according to the device form and functional requirements, better matching the personalized needs of scenarios.
Brand Value Empowerment by SincereFirst
As a brand deeply engaged in the optical and camera module industry for over 30 years, SincereFirst has always integrated the concept of “solid quality and thoughtful service” into the entire product lifecycle — from the construction of Class 10/100 cleanrooms to the industry-standard experience accumulated through cooperation with Fortune 500 companies, every module produced embodies the pursuit of “stability” and “reliability”.
To address customer concerns, we provide a 1-year replacement service and a 10-year warranty commitment, eliminating after-sales worries with long-term protection. In the face of differentiated needs across industries, our one-stop OEM services — from parameter customization to structural optimization — turn modules from “general-purpose parts” into “exclusive solutions” that can be deeply adapted to customers’ products.
If you are looking for a camera module with high image quality, high stability, and flexible adaptability for smartphones, security, automotive, or industrial equipment, please feel free to contact SincereFirst. With 30 years of technical accumulation as support, we will provide customized suggestions based on your specific needs, making every image clear and powerful to enhance the competitiveness of your products.
