Global Shutter External Trigger Dynamic Capture 5MP USB Camera Module

Product Introduction:

This is a global shutter external trigger dynamic capture 5MP USB camera module, a high-performance, high-speed, and high-precision industrial USB camera module under the brand SincereFirst. Equipped with a high-sensitivity CMOS sensor, it features 5MP resolution, supporting a maximum output of 2560×1440 resolution images and stable 60FPS frame rate, balancing detailed presentation and dynamic smoothness.

With a sensor size of 1/2.5 inch and a large pixel design of 2.2μm×2.2μm, it effectively improves imaging quality in low-light environments. It supports MJPG and YUY2 output formats, offering both lossless and compressed options to adapt to different data transmission and processing needs. The focusing range covers 1cm to infinity, paired with manual focusing, making it perfectly suitable for various shooting distances.

Its core features include global shutter and global exposure technologies, which eliminate motion blur in dynamic images. Additionally, it is equipped with an external trigger function that can precisely control shooting timing via external signals, enabling millisecond-level accurate image capture. The module has a compact size of only 38mm×38mm, uses a USB 2.0 interface for data transmission, and is compatible with the UVC protocol, supporting plug-and-play functionality across mainstream operating systems.

Manufactured in SincereFirst’s Class 100 cleanroom using SMT (ROHS) environmental protection technology and Active Alignment (AA) process, the product further ensures stable long-term operation in industrial scenarios.

Product Advantages & Features

Ultra-Clear Dynamic Capture: Global shutter and global exposure technologies enable simultaneous exposure of the entire frame. Compared with rolling shutters, they completely eliminate the “jello effect” of fast-moving objects. Even when shooting high-speed moving mechanical parts or objects, it maintains clear edges and true shapes.
Precise Synchronization: The external trigger function supports receiving signal commands from external devices (such as photoelectric sensors, encoders, or PLCs), enabling microsecond-level response for synchronized shooting. It can accurately capture instantaneous states at specific time points, solving the problems of “missing key frames” or “excessive redundant data” in traditional free-shooting modes and improving data collection efficiency.

3. QHD Imaging: The combination of 2560×1440@60FPS high resolution and high frame rate delivers 2.5K-level detailed images. Combined with the 1/2.5-inch sensor and 2.2μm large pixel design, it enhances light-sensing capability, reduces noise in low-light conditions, and maintains image purity.

4. Flexible Adaptability: With a compact size of 38mm×38mm, it is easy to embed in devices with limited space. The USB 2.0 + UVC protocol supports cross-system plug-and-play, simplifying the connection process with computers and embedded motherboards.

5. Stability & Reliability: Relying on SincereFirst’s Class 100 cleanroom COB automated production workshop and AA process, it ensures precise alignment between the lens and sensor. Combined with ROHS environmental standards and authoritative certifications such as ISO, CE, and FCC, it meets the requirements for long-term stable operation of industrial-grade equipment.

6. Full-Scenario Coverage: The ultra-wide focusing range from 1cm to infinity, paired with manual focusing, eliminates the need for frequent lens replacement, reducing maintenance costs. It can adapt to diverse scenarios from macro inspection to long-distance monitoring.

Product Application

Industrial Automation Inspection: Suitable for product quality inspection on high-speed production lines. Through synchronization between the external trigger function and production line encoders, it accurately triggers shooting at specific workstations. The global shutter ensures distortion-free images of moving products, enabling detection of part defects, assembly integrity, and more.
Dynamic Capture & Analysis: Used in fields such as sports biomechanics analysis and robot motion trajectory recording. By synchronizing the external trigger with the motion platform, it captures high-speed motion sequences. The global shutter ensures no deformation in each frame, providing accurate visual support for data research.
Intelligent Measurement: Applied in scenarios like 3D scanning and stereo vision measurement. Multiple cameras can achieve fully synchronized capture via external triggers, ensuring temporal consistency of multi-angle images. The global shutter prevents image deformation from affecting measurement accuracy.
Intelligent Barcode Recognition: Installed next to sorting robotic arms, the global shutter clearly captures barcodes on high-speed moving packages. The external trigger links with the robotic arm’s motion signals, and combined with 2.5K resolution, it enables fast long-distance recognition, making it suitable for intelligent warehousing scenarios.

Brand Value Empowerment by SincereFirst

From the performance and quality of this global shutter & external trigger USB camera module, SincereFirst’s brand philosophy of “Sincere is First” is clearly reflected:

30 years of industry experience lays a solid technical foundation;
Its product line covering 0.1MP to 200MP resolution meets diverse needs;
Class 100 cleanrooms and authoritative certifications guarantee quality;
A monthly production capacity of 3 million modules supports large-scale applications;
“Custom solutions in one week” and “coverage in over 200 countries and regions” demonstrate its rapid response and global service capabilities.

Whether for the precise needs of industrial inspection, professional standards for dynamic analysis, or flexible adaptation to intelligent scenarios, SincereFirst creates value for customers with its “high performance, high reliability, and customization” product characteristics. Behind the “compact design and stable performance” is the brand’s in-depth cultivation of optical imaging technology and its continuous commitment to “customer satisfaction”. For enterprises pursuing quality and adaptability, SincereFirst is not just a supplier of camera modules, but a reliable partner for optical imaging systems.
